D5 2.0 ST (Step-Through) by Himiway

Meet your new Himiway D5 2.0 ST

The ST is for Step-Though, making getting on and off a breeze.  Prepare to find yourself heading outdoors more often, riding further, and exploring with unmatched comfort and ease.

Industry-Leading Electrical Safety

• UL 2849 Certified:  This is the gold standard for eBike electrical systems.  It means the entire drive train - including the motor, computer, and charger - has undergone rigorous testing to prevent electrical failures and fire risks.
• UL 2271 Certified:  This specifically covers the lithium-ion battery.  It ensures the "heart" of your bike is protected against overcharging, short-circuiting, and impact, providing a safer charging experience in your home or garage.

Advanced Weather & Waterproofing

• IPX5 and IPX6 Certified Components: Engineered to confidently handle the elements, the D5 2.0 ST features split-system water protection. The entire bike and its core electrical components carry a robust IPX5 rating, making them thoroughly resistant to sustained rain, wet road splashes, and damp weather. Taking protection a step further, the critical battery casing is independently certified to a strict IPX6 rating, ensuring the high-capacity cells remain completely dry and sealed even against high-pressure water streams or sudden downpours.

Meet your new ride:

• 70 Miles of Pedal Assist Range or 40 Miles of Throttle Range.  A 720 Wh, 15 Ah battery powers is perfect for daily commutes or extended adventures.  Think of Watt-hours as being the size of your gas tank.  (The average mid-range eBike has around 500 to 650 Wh).
• 28 MPH Max Speed
• Watts with the Torque?

  The D5 2.0 ST is propelled by a robust 48V, 750W geared hub motor that serves up a massive 90 Nm of torque. This heavy-duty power configuration means you can effortlessly flatten steep inclines, accelerate smoothly from a dead stop, and handle any trail with ease. Unlike standard e-bikes, the D5 2.0 utilizes an advanced dual-sensor system (combining both torque and cadence sensors) paired with a Smart Auto Pedal Assistant and 5 levels of PAS. By measuring both how fast and how hard you are pedaling, the motor delivers a remarkably natural, lag-free power boost that optimizes efficiency—yielding an impressive 70-mile pedal-assist range or a 40-mile pure-throttle range using the ergonomic thumb throttle.

  Out of the box, the bike is programmed with a default maximum speed of 20 MPH, but it can be easily adjusted to achieve a top speed of 28 MPH. This flexibility allows you to seamlessly configure the electronics to match your local riding laws, giving you the ability to switch the bike between Class I, Class II, or Class III operational modes.

• What Class Rating does the D5 2.0 ST have and why should I care?  This premium eBike offers the ultimate flexibility, capable of switching between Class I, Class II, and Class III modes.  While it ships as a Class II, you can easily unlock its full potential through the colorful LED control panel.
  • Understanding the Class Ratings:  Why Versatility Matters:
    • Class I (Pedal Assist Only):  The motor provides assistance only when you are pedaling and ceases to provide help once you reach 20 MPH. This mode is often required for specific mountain trails or multi-use paths that prohibit throttles.
    • Class II (Throttle & Pedal Assist):  This is the "out of the box" setting.  The bike includes a throttle that can propel you up to 20 MPH without any pedaling required, perfect for effortless cruising or getting a boost from a standstill.
    • Class II (High Speed):  This unlocks the eBike's top speed of 28 MPH via pedal assist.  It is the ideal setting for commuters who need to keep pace with city traffic and cover long distances quickly.
    • Understanding local and state ebike regulations is essential because laws vary significantly regarding where different class types are permitted, and staying informed ensures you can enjoy the full range of "Class I/Class II/Class III freedom" while remaining legally compliant and safe on every road and trail.
• Battery and Charger:  The D5 2.0 ST is powered by a high-performance 48V 15Ah battery pack built with premium, automotive-grade Samsung or LG 21700 cells. Engineered for extreme safety, reliability, and longevity, the entire battery pack is officially UL 2271 certified, while the individual cells carry the gold-standard UL 2580 safety certification. The housing features a robust IPX6 waterproof rating, providing heavy-duty protection against high-pressure water streams and severe weather. To minimize your downtime between rides, the system includes a powerful 48V 3.0A fast charger, allowing you to quickly replenish the high-capacity cells and get back out on your next trek with minimal waiting.
• Shimano 8-Speed Gears: The D5 2.0 ST features a high-performance Shimano 8-speed drivetrain engineered for smooth, reliable shifting across varied terrains. The mechanical system centers around a premium 52T Narrow-Wide chainring mounted to a durable 170mm aluminum alloy crankset. The specialized narrow-wide tooth profile dramatically improves chain retention, virtually eliminating dropped chains on rough trails. Paired with a versatile 13-32T 8-speed freewheel, an authentic Shimano rear derailleur, a matching Shimano shift lever, and an e-bike-rated 8-speed chain, this gearing configuration provides the perfect mechanical range to efficiently tackle steep climbs and maintain comfortable pedaling cadences at top speeds.
• Hydraulic Disc Brakes:  The D5 2.0 ST is equipped with a premium Tektro hydraulic disc braking system engineered for maximum stopping power and precise control. This setup pairs an oversized 203mm front rotor with a 180mm rear rotor, offering superior heat dissipation and exceptional braking leverage under heavy loads or high speeds. The system is operated via durable aluminum alloy brake levers that feature an integrated electronic power cutoff mechanism. The moment you pull the levers, power to the motor is instantly disconnected, ensuring rapid, safe, and reliable stops in any weather or terrain condition.
• 26" x 4" Fat Tires:  The D5 2.0 ST comes factory-equipped with premium Maxxis Minion FBF (Front) and FBR (Rear) 26" x 4.0" fat tires. Engineered specifically for high-performance fat biking, these tires feature a trail-proven, aggressive tread pattern designed to bite deep into loose terrain, snow, sand, and mud while maintaining a smooth rolling resistance on hardpacked surfaces. For the ultimate upgrade in performance, these tires are completely tubeless-ready, allowing you to run lower tire pressures for an ultra-cushioned ride, maximum ground traction, and superior puncture resistance without the weight of traditional inner tubes.
  • What does "tubeless-ready" mean?  Out of the box from the factory, it will arrive with a standard inner tube installed inside the tire. "Tubeless-ready" means the tire casing and the wheel rim are designed with a precise, airtight bead lock so that, if you choose to, you can switch to tubeless.
• Strong and Lightweight Alluminum Alloy Frame:  Built to handle the demands of both rugged exploration and smooth city cruising, the D5 2.0 ST is engineered around a premium, high-strength 6061 Aluminum Alloy frame. This robust chassis features a low-profile step-through design for effortless mounting and dismounting without sacrificing structural strength. The frame provides a rock-solid, stable foundation that ensures predictable handling, a heavy-duty 400 lb. total payload capacity, and crisp responsiveness on every single journey.
• Suspension:  The D5 2.0 ST features an advanced full-suspension system engineered to deliver top-tier comfort and stability across city pavement and rugged backcountry trails alike. Up front, a 90 mm adjustable suspension fork absorbs heavy impacts from roots and ruts, while the responsive 100 mm rear travel system works in tandem to isolate shocks and drastically reduce jarring vibrations. Working together with its rugged 4-inch fat tires, this full-suspension setup maximizes ground traction, keeps you in total control, and provides an ultra-cushioned, floating ride no matter how wild the terrain gets.
• Start me Up!  The D5 2.0 ST is ready to go with the start of a button on the control pad!
• Is this a folding eBike?  No.  The D5 2.0 ST does NOT fold.
• Lights, Displays, and Safety Features:  Engineered for both city streets and rugged trails, the D5 2.0 ST features a fully unified safety setup to keep you protected on every ride. You'll stay completely aware of your surroundings with an intuitive handlebar controller that operates a strong headlight, a loud built-in horn, and a reactive brake light. Best of all, it features factory-integrated turn signals, making it easier than ever to communicate your moves to traffic and ride with peace of mind.
• 400 Max Load Weight:  The D5 2.0 ST supports 400 pounds combining the rider and any cargo.
• Is the D5 2.0 ST your size?  The recommended rider height for the D5 2.0 ST is 5'1" through 6'5".  The recommended inseam is 27" through 35".  The "ST" part of this eBike model stands for "step-through" meaning it features a low step-through frame for easy on and off.

• Does the D5 2.0 ST have a sturdy kick stand?  Yes!
